Leisure Products (Bolton) Ltd

Design • Develop • Manufacture

The Neptune 4500 The Neptune 4500 is a marine grade unit and features twin burners, a compact grill compartment and an oven. There are three models available, as shown below, please read the specification carefully and contact your local chandlery should you wish to discuss your requirements.

• 1 x large rapide hob burner • 1 x standard semi rapide hob burner • Integrated pan clamps and gimbals • Painted body panels

Technical Specifications:

A: Base to top of seal rail

Base to top of spillage tray

B: Base to top of pan support

C: Base to gimbal point

D: Cooker width

E: Gimballed width

F: Gimbal Arc

G: Gimbal point to back stop

H: Cooker depth

560

485

505

475

450

470

510

225

420

A: Base to top of sea rail

Base to top of spillage tray

B: Base to top of pan support

C: Base to gimbal point

D: Cooker width

E: Gimballed width

F: Gimbal Arc

G: Gimbal point to back stop

H: Cooker depth

560

485

505

475

450

470

510

225

420

Available Models:

• 1 x large rapide hob burner • 1 x standard semi rapide hob burner • Electric spark ignition • Integrated pan clamps and gimbals • Stainless steel body panels

• 2 x large rapide hob burner • Electric spark ignition • New stainless ignition switch • Integrated pan clamps and gimbals • Integrated gimbal lock • Stainless steel body panels • High gloss black on stainless steel door

All burners are protected by flame failure safety cut-outs Door safety catch to prevent the door opening if the boat heels Can be used on butane or propane Max heat input - 6.81 kW (494 g/h) Weight - 20kg

Standard across all models

Neptune Deluxe

Neptune Standard

Neptune Economy

Leisure Products (Bolton) Ltd

Design • Develop • Manufacture

The Neptune/Voyager 4500

The 4500 is the latest generation of the ever popular Neptune/Voyager modular range. Whilst retaining all the features that made it the most popular cooker in it’s class, the new 4500 comes with a larger and more powerful hob burners. Furthermore, the door handle has been redesigned in aluminium which compliments the new silver knob control. The new, stronger, pan support is also a breeze to fit and secure in one place.

Key features:

• 1 x large rapide hob burner • 1 x standard semi rapide hob burner • A thermostatically controlled oven • A compact yet powerful grill in it’s own compartment • All burners are protected by flame failure safety cut-outs • Available with electric spark ignition fitted to all burners • Door safety catch to prevent the door opening if the boat heels • Can be used on butane or propane
